Specifications

Product Type	Changeover Switch
Brand	ABB
Cable Cross Section	10-70 sq-mm
Colour	Black
Control Element Colour	Black
Degree of Pollution	IP3
Degree of Protection	IP20
Depth	86 mm
Height	100 mm
Interlockable	Yes
Mode of Operation	Front
Mounting Type	4-Hole Front Mount
NEMA Rating	NEMA 1
Number of Poles	3
Number of Switches	1
Power Loss	4 W
Rated Current	100 A
Rated Impulse Withstand Voltage	8 kV
Rated Insulation Voltage	750 V
Rated Power	37 kW
Rated Short Time Withstand Current	2.5 kA
Rated Voltage	415 VAC
Suitable For Use With	Distribution Board Installation
Terminal Type	Screw Clamp
Tightening Torque	6 N-m
Transition Type	Open
Weight	0.9 kg
Width	140 mm
