Specifications

Product Type	Enclosed switch disconnector
Brand	ABB
Series	OTP
Application	Safety isolation and switch-disconnector applications
Rated Impulse Withstand Voltage (Uimp)	0.5 kV
Rated Insulation Voltage (Ui)	750 V
Short-time Withstand Current	0.5 kA
Suitable For	Distribution Board Installation
Utilization Category	AC-23
Breaking Capacity	Icm 0.705 kA at 690 V AC
Power Loss	0.3 W
Rated Current	16 A
Rated Frequency	50/60 Hz
Rated Power	7.5 kW
Rated Voltage	750 V AC
No. of Poles	3P
Body Style	Enclosed
Cable Cross Section	0.75-10 sq-mm
Cable Entry	Top/Bottom; 2 x M20 per side
Colour	Grey enclosure / black selector handle
Colour Control Element	Black
Connection/Termination	Screw terminals; 0.75 - 10 mm²
Handle Type	Selector
Material	Rigid glass-reinforced polycarbonate enclosure
Mounting	Surface mounted enclosure
Rated Impact Resistance	IK08
Tightening Torque	0.8 N-m
Depth	60 mm
Height	120 mm
Weight	0.44 kg
Width	85 mm
Pollution Degree	3
IP Rating	IP65
NEMA Rating	NEMA 1
Standards and Approvals	IEC 60947-1, IEC 60947-3, RoHS, REACH, CE, WEEE
Standards	IEC 60947-1 & -3
Certifications / Approvals	CE
