Specifications

Product Type	Safety switch
Brand	ABB
Series	OTP
Application	Safety isolation and switch-disconnector applications
Utilization Category	AC-23
Breaking Capacity	Icm 2.1 kA at 690 V AC
Power Loss	4.5 W
Rated Current	45 A
Rated Frequency	50/60 Hz
Rated Voltage	750 V AC
No. of Poles	3P
Body Style	Enclosed
Cable Cross Section	1.5-35 sq-mm
Cable Entry	Top/Bottom; 2 x M32 + M16 per side
Colour	Grey enclosure / red-yellow selector handle
Colour Control Element	Red
Connection/Termination	Screw terminals; 1 NO auxiliary; 1.5 - 35 mm²
Handle Type	Selector
Material	Rigid glass-reinforced polycarbonate enclosure
Mounting	Surface mounted enclosure
Depth	90 mm
Height	200 mm
Weight	0.9 kg
Width	145 mm
IP Rating	IP65
Standards and Approvals	IEC 60947-1, 3
Standards	IEC 60947-1 & -3
Certifications / Approvals	CE
