Specifications

Product Type	Soft Starter
Brand	AuCom
Built-in Bypass	Yes
Rated Control Supply Voltage (Us)	110/240 VAC
Rated Current Ie - Heavy Duty	49 A
Rated Current Ie - Normal Duty	60 A
Rated Operational Voltage (Ue)	200-440 VAC
Rated Power at 400V (Pe) - Normal Duty	30 kW
Control Features	Current Ramp
Rated Frequency	45-66 Hz
Depth	165 mm
Height	201 mm
Weight	2.2 kg
Width	98 mm
IP Rating	IP20
Ambient Temperatures	-10 to +60 °C
Standards and Approvals	IEC 60947-4-2; EN 60947-4-2; UL 508
