Specifications

Product Type	Pressure Transmitter
Brand	BD Sensor
Series	DMP 331P
Output Signal	4-20 mA
Electrical Connection	male plug M12x1 (4-pin), metal
Input Signal	10 bar
Material	stainless steel1.4404 (316 L)
Mechanical Connection	G1/2" with flush welded diaphragm (DIN 3852)
Weight	min. 200 g
IP Rating	IP 67
Ambient Temperature	-40 ... 85 °C
