Specifications

Product Type	Pressure Transmitter
Brand	BD SENSORS
Series	DMP 457
Accuracy	>=0.4 bar, 0.35% FSO
Application	Diesel Engines, Drives, Compressors, Pumps, Boiler, Hydraulic and Pneumatic Control Systems.
Electrical Connection	Field Housing 316L Stainless Steel
Mechanical Stability	4 g (according to DNV: class B, curve 2 / basis: IEC 60068-2-6).
Mechanical Connection	1/2 in NPT
Mechanical Life	10000000 Operations
Operational Life	100 million load cycles.
Operational Temperature	-40 to 125 deg C
Output Type	4-20 mA
Rated Pressure	40 bar
Response Time	<=10 ms
Seal Material	FKM
Version	Standard
