| Product Type |
Firewall |
| Brand |
Hirschmann |
| Series |
OpenBAT-R / -F |
| Development Software |
WLAN Controller, Industrial HiVision, LANConfig |
| Connectors |
3× RP-SMA Female for each WLAN interface, requires antennas with RP-SMA Male connectors |
| Rated Power |
max. 12.95W , second WLAN module adds max. 4.55W to a total of 17.5W |
| Rated Voltage |
Power 1: 24 VDC , Power 2: 24 VDC |
| Material |
metal |
| Mounting Type |
DIN-Rail |
| Depth |
121 mm |
| Height |
145 mm |
| Weight |
1300 g |
| Width |
121 mm |
| Storage Temperature |
-40-+85 °C |
| IP Rating |
IP20 |
| Port Type |
Ethernet 1: ComboPort 10/100/1000 via RJ45 or SFP , Ethernet 2: 10/100/1000 via RJ45 |
| USB Port |
Can be disabled in software., USB Type A socket, compatible with ACA21-USB EEC and ACA22-USB EEC |
| Radio Frequency |
Freely configurable between 2.4 GHz and 5 GHz independently on each WLAN interface: 2400 -2483.5 MHz (ISM) and 5170 -5850 MHz (additional regulatory restrictions apply depending on the country of operation) |
| Modulation |
20M0F7D (DSSS/OFDM) @ 2.4 GHz, 20M0G7D (OFDM) @ 5 GHz, MCS 0 - MCS23 |
| Radio Features |
WLAN 1: 3x3 MIMO, up to 3 streams (configurable) . Integrated ESD protection, Clear Space® . WLAN 2: 3x3 MIMO (configurable), up to 3 streams (configurable) |
| Encryption |
Open, WEP, 802.11i - WPA/WPA2 - Personal (PSK), 802.11i - WPA/WPA2 - Enterprise (802.1X: TLS, TTLS/PAP, TTLS/CHAP, TTLS/MSCHAP, TTLS/MSCHAPV2, TTLS/MD5, PEAP/MSCHAPV2), WPA3 Personal and Enterprise (AES-CCMP-128, AES-CCMP-256, AES-GCMP-128, AES-GCMP-256) |
| Communication Protocols |
IEEE 802.11a/b/g/n WLAN as per IEEE 802.11n |
| Standards and Approvals |
IEC/EN 60950-1
EN50121-4, EN50121-3-2, , EN50155, EN45545-2
EN 300 328 (2.4 GHz), EN 301 893 (5 GHz), EN 302 502 (5.8 GHz) |
