Specifications

Product Type	2-Input/1-Output Universal Analog Module
Brand	IDEC
Series	MicroSmart FC6A
Analog Resolution	Up to 16 bit input, 12 bit output
Digital Inputs	0
Digital Outputs	0
Output Ratings	0 to 10 V DC, -10 to 10 V DC, 0 to 20 mA, 4 to 20 mA
Analog Outputs	1
Input Ratings	0 to 10 V DC, -10 to 10 V DC, 0 to 20 mA, 4 to 20 mA
Input Type	Voltage, current, thermocouple, RTD
Output Type	Voltage, current
Supply Voltage	12 V DC, 24 V DC
Terminal Type	Screw terminal
Analog Inputs	2
Mounting Method	DIN rail or panel
Depth	73 mm
Height	90 mm
Width	23.6 mm
Storage Temperature	-25 to 70 °C
Operating Temperature	-25 to 65 °C; voltage output -25 to 55 °C
IP Rating	IP20
Hazardous Location Ratings	Class I Div 2
Compliance Standards	CE, UL, TÜV
