Specifications

Product Type	Multi-Function Timer
Brand	IDEC
Series	GT3
Contact Type	Delayed SPDT + Instantaneous SPDT
Timing Range	0.1s to 180h
Contact Configuration	2 SPDT
Rated Current	5A
Rated Power	0.9 W, 1.8 VA
Rated Voltage	24V AC/DC
Terminal Type	Pin
No. of Pins	8
Depth	72.2mm
Height	40mm
Width	36mm
Pollution Degree	2
Operating Temperature	-30 to 80 deg C
IP Rating	IP40 (timer), IP20 (socket)
Ambient Temperature	-10 to +50°C
Standards and Approvals	CE, cUL Listed File E55996, EN61812-1:2011, ENIEC 63000:2018, UL
