Specifications

Product Type	Multi-Function Timer
Brand	IDEC
Series	GT3A
Contact Configuration	Delayed DPDT
Degree of Pollution	IP2
Degree of Protection	IP20, IP40
Insulation Resistance	100 MOhm
Number of Pins	8
Operating Time	0.1 s-180 hr
Operational Temperature	-30 to 80 deg C
Rated Power	0.9 W, 1.8 VA
Rated Voltage	24 VDC
Standards and Approvals	CE, cUL Listed File E55996, EN61812-1:2011, ENIEC 63000:2018, UL
Terminal Type	Pin
