Specifications

Product Type	HMI
Brand	IDEC
Series	HG series
Development Software	Automation Organizer (WindO/I-NV4)
Channel Isolation	1,000V AC between power and FG terminals
Power Consumption	25W
Supply Voltage	24V DC
Sunlight Readable	Yes (Super Bright 600 cd/m²)
Display Colour	65,536 colors
Mounting Method	Panel Mount
Depth	54.1 mm
Height	240 mm
Width	314 mm
Panel Cut-Out Size	301.5 x 226.5 mm
Display Size	12.1 inch
Storage Temperature	-20 to 70°C
Operating Temperature	-20 to 60°C
IP Rating	IP66F/IP67F
Ethernet Ports	1
Expandable Communications	Up to 4 Expansion Modules (discrete/analog I/O)
Fieldbus Interface	Supports Ethernet-based and serial fieldbuses
Serial Ports	2
USB Port	1
Supported Ethernet Protocols	FTP, Email, Web Server, BACnet/IP, Modbus TCP/IP
Supported Serial Protocols	Over 100 protocols supported; Modbus RTU
Touch Type	Analog resistive membrane
Hazardous Location Ratings	Class I Division 2
Compliance Standards	CE, UL61010, TUV, CSA
