Specifications

Product Type	Switching Power Supply
Brand	IDEC
Series	PS5R-V
Diagnostics	LED (green)
Input Voltage	85-264 V AC / 100-370 V DC
Output Current - Nominal	1.3 A
Output Current - Range	1.3 A
Output Power	15 W
Output Voltage - Nominal	12 V DC
Output Voltage - Range	10.8-13.2 V DC
Efficiency	80-82%
Terminal Type	M3.5 screw terminal
Mounting Style	DIN Rail
Depth	95 mm
Height	90 mm
Weight	0.140 kg
Width	22.5 mm
Approvals / Conformity	UL508, UL1310 Class 2, ANSI/ISA-12.12.01, CSA C22.2 No.107.1, CSA C22.2 No.213, CSA C22.2 No.223, EN60950-1, EN50178, EN61204-3, CE, RoHS, TUV
Operating Temperature	-25 to 75°C
IP Rating	IP20
