Specifications

Product Type	Power Supply
Brand	IDEC
Series	PS5R - V
Input Voltage DC	100-240V AC
Output Power	30W
Output Voltage - Nominal	24V DC
Efficiency	100V AC: 85%
Rated Current	700-300 mA
Rated Frequency	50/60 Hz
Rated Power	30 W
Rated Voltage	85-264 VAC, 24 VDC
Terminal Type	Spring-up terminals
Mounting Style	DIN rail
Mounting Type	DIN Rail
Depth	95 mm
Height	22.5 mm
Weight	150 g
Width	90 mm
Approvals / Conformity	UL508 (Listing), UL1310 Class 2, ANSI/ISA-12.12.01 CSA C22.2 No. 107.1, 213, 223 EN60950-1, EN50178
Operating Temperature	-25 to +70°C
Standards and Approvals	cUL us, CE, UL us, CE, UL 508, ANSI/ISA 12.12.01, CSA C22.2 No.107.1, 213, 223
