IDEC RJ1S-CL-D24 Slim General Purpose Relay SPDT 12A Plug-In Terminal

Product Code: RJ1S-CL-D24

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type Slim Power Relay
Brand IDEC
Series RJ
Actuating Voltage 19.2 VDC
No. of N/C Contacts 1
No. of N/O Contacts 1
Electrical Connection Blade
Rated Voltage 24 VDC
Rated Coil Current 48 mA
Contact Rated Current 12 A
Change-Over Contacts SPDT
Contact Material Silver-nickel alloy
Mounting Type Socket Mounting
Depth 12.7 mm
Height 27 mm
Width 31.1 mm
Operating Temperature –40 to +70°C
IP Rating IP40

Documents

IPD Product Catalogue V17
IDEC Catalogue

Certificate

CSA Certification
EU Declaration of Conformity

CAD Blocks & Dimensions
