IDEC RJ1S-CLR-A240 Slim General Purpose Relay SPDT Push-In Terminal

Product Code: RJ1S-CLR-A240

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type Slim General Purpose Relay
Brand IDEC
Coil Voltage 240 VAC
Contact Configuration SPDT
Contact Material Silver Nickel Alloy
Contact Resistance 50 MOhm
Degree of Protection IP40
Electrical Life 200000 Operations
Humidity 5-85%
Mechanical Life 3000000 Operations
Number of Poles 1
Operating Time 15 ms
Operational Temperature -40 to 70 deg C
Shock Resistance 1000 ms
Standards and Approvals CE, CSA, RoHS, VDE
Terminal Type Push-In
Vibration Resistance 10-55 Hz

Documents

IPD Product Catalogue V17
IDEC Catalogue

Certificate

CSA Certification
EU Declaration of Conformity
