IDEC RJ2S-CL-A24 Slim Power Relay DPDT 24VAC Coil 8A Blade Terminal

Product Code: RJ2S-CL-A24

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type Slim Power Relay
Brand IDEC
Series RJ
Actuating Voltage 19.2 VAC
No. of N/C Contacts 2
No. of N/O Contacts 2
Electrical Connection Blade
Rated Voltage 24 VAC
Rated Coil Current 47.5 mA
Contact Rated Current 8 A
Change-Over Contacts DPDT
Contact Material Silver-nickel alloy
Mounting Type Socket Mounting
Depth 12.7 mm
Height 27 mm
Width 31.1 mm
Operating Temperature –40 to +70°C
IP Rating IP40

Documents

IPD Product Catalogue V17
IDEC Brochure
IDEC Catalogue

Certificate

CSA Certification
EU Declaration of Conformity

CAD Blocks & Dimensions
