Specifications

Product Type	Analog Timers
Brand	IDEC
Series	RTE
Electrical Endurance	500000 Operations
Over Voltage Category	Category III
Timing Range	0.1sec to 600 hours
Rated Power	1.7 W
Rated Voltage	24V AC(50/60Hz)/24V DC
Terminal Type	Pin
Response Time	98 ms
Mechanical Durability	50000000 Operations
Vibration Resistance acc. To IEC/EN 60068-2-6	10-50 Hz
Depth	90.9 mm
Height	40 mm
Weight	89 g
Width	36 mm
Operating Temperature without Derating	-20 to +65ºC (without freezing)
Pollution Degree	2
Humidity	35-85%
Operating Temperature	-20 to 65 deg C
IP Rating	IP40 (enclosure) (IEC60529)
Standards and Approvals	CE, cULus, UL Listed File E66043
