Specifications

Product Type	Universal Relay
Brand	IDEC
Series	RU
Actuating Voltage	176 V AC - 192 V AC
No. of N/C Contacts	2
No. of N/O Contacts	2
Timing Range	20 ms
Contact Configuration	DPDT
Electrical Connection	Blade Terminal
Rated Current	10 A
Rated Voltage	220 V AC - 240 V AC
Terminal Type	Plug-In
Timer Relay Type	RU2 2PDT Relay with LED indicator
Change-Over Contacts	DPDT
Mechanical Durability	50000000 Operations
With Base	SM2S-05C
Contact Material	Silver alloy
Mounting Type	With Sockets (DIN, Finger-Safe DIN, Through Panel, PCB)
Vibration Resistance acc. To IEC/EN 60068-2-6	10-55 Hz
Depth	35.6 mm
Height	27.5 mm
Weight	35 g
Width	21 mm
Humidity	5-85%
Operating Temperature	–55 to +60°C (no freezing)
Standards and Approvals	CE, CSA, Lloyd Register, UKCA
