Specifications

Product Type	Universal Relay
Brand	IDEC
Series	RU
Actuating Voltage	88 V DC
No. of N/C Contacts	2
No. of N/O Contacts	2
Timing Range	20 ms
Contact Configuration	DPDT
Electrical Connection	Blade Terminal
Rated Current	10 A
Rated Voltage	110 V DC
Response Time	150 ms
Change-Over Contacts	DPDT
Mechanical Durability	100000000 Operations
Contact Material	Silver alloy
Model	With Diode(DC Coil Only)
Mounting Type	With Sockets (DIN, Finger-Safe DIN, Through Panel, PCB)
Vibration Resistance acc. To IEC/EN 60068-2-6	10-55 Hz
Depth	35.6 mm
Height	27.5 mm
Weight	35 g
Width	21 mm
Humidity	5-85%
Operating Temperature	–55 to +60°C (no freezing)
Standards and Approvals	CE, CSA, Lloyd Register, UKCA
