Specifications

Product Type	Pushbutton
Brand	IDEC
Series	YW
Actuator Type	Flush
Bezel Material	Plastic
Button Colour	Green
Colour	Green
Contact Configuration	2NO
Contact Material	Silver
Cutout Size	22 mm
Degree of Protection	IP65 Front, IP20 Terminal
Depth	56.8 mm
Diameter	22 mm
Function	Momentary
Height	41.4 mm
Humidity	45-85%
Illumination	Non-Illuminated
Insulation Resistance	100 MOhm
Mechanical Life	5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model	Flush Momentary
Operational Temperature	-20 to 55 deg C
Rated Continuous Current	10 A
Rated Insulation Voltage	600 V
Shock Resistance	10 g/ms
Standards and Approvals	cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature	-40 to 85 deg C
Terminal Type	Screw
Vibration Resistance	5-55 Hz
Width	30 mm
