Specifications

Product Type	Pushbutton
Brand	IDEC
Series	YW
Actuator Type	Mushroom
Bezel Material	Plastic
Bezel Type	Plastic
Contact Configuration	1NO
Contact Material	Silver
Cutout Size	40 mm
Degree of Protection	IP65 Front, IP20 Terminal
Depth	64.8 mm
Diameter	40 mm
Function	Momentary
Height	41.4 mm
Humidity	45-85%
Illumination	Illuminated
Insulation Resistance	100 MOhm
Lamp Colour	Amber
Lamp Type	Without Lamp
LED Colour	Amber
Mechanical Life	5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Mode of Operation	Momentary
Operational Temperature	-20 to 55 deg C
Rated Continuous Current	10 A
Rated Insulation Voltage	600 V
Rated Voltage	250 VAC/DC
Shock Resistance	10 g/ms
Standards and Approvals	cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature	-40 to 85 deg C
Terminal Type	Screw
Vibration Resistance	5-55 Hz
Width	30 mm

IDEC YW1L-M4E10Q0A Illuminated Pushbutton 40mm Mushroom Momentary Amber 250VAC/DC 1NO
