Specifications

Product Type	Pilot Light With LED
Brand	IDEC
Series	YW
Ambient Temperature	-30 to 70 deg C
Colour	Brown
Connecting Capacity	1/2 x 0.75-2.5 sq-mm Flexible with Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible with Insulated Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible, 1/2 x 0.75-2.5 sq-mm Solid
Connection Type	Screw Clamp
Contact Configuration	1NC
Degree of Pollution	IP3
Degree of Protection	IP20
Depth	27.7 mm
Height	39.5 mm
Lamp Type	Included
Model	Transformer Type
Mounting Type	Front
Operational Temperature	-30 to 70 deg C
Rated Frequency	50/60 Hz
Storage Temperature	-40 to 70 deg C
Terminal Type	Screw (M3.5)
Tightening Torque	0.9 N-m
Width	9.6 mm
Wire Stripping Length	10 mm
