Specifications

Product Type	Pilot Light Without Lamp
Brand	IDEC
Series	YW
Ambient Temperature	-30 to 70 deg C
Colour	Brown
Connecting Capacity	1/2 x 0.75-2.5 sq-mm Flexible with Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible with Insulated Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible, 1/2 x 0.75-2.5 sq-mm Solid
Connection Type	Screw Clamp
Contact Configuration	1NO+1NC
Degree of Pollution	IP3
Degree of Protection	IP20
Depth	48 mm
Height	39.9 mm
Lamp Type	Not included
Model	Replacement Lamp Type
Mounting Type	Front
Operational Temperature	-30 to 70 deg C
Rated Impulse Withstand Voltage	4 kV
Rated Insulation Voltage	690 V
Storage Temperature	-40 to 70 deg C
Terminal Type	Screw
Tightening Torque	0.9 N-m
Weight	0.05 kg
Width	9.6 mm
Wire Stripping Length	10 mm
