Specifications

Product Type	Pushbutton
Brand	IDEC
Series	YW
Actuator Type	Flush
Bezel Material	Metal
Button Colour	Black
Colour	Black
Contact Configuration	1NO
Cutout Size	22 mm
Degree of Protection	IP65 Front, IP20 Terminal
Depth	64.8 mm
Diameter	22 mm
Function	Momentary
Height	41.4 mm
Humidity	45-85%
Illumination	Non-Illuminated
Insulation Resistance	100 MOhm
Mechanical Life	5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model	Flush - Momentary
Operational Temperature	-20 to 55 deg C
Rated Continuous Current	10 A
Rated Insulation Voltage	600 V
Shock Resistance	10 g/ms
Standards and Approvals	cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature	-40 to 85 deg C
Vibration Resistance	5-55 Hz
Width	30 mm
