Specifications

Product Type	Fuse fitting
Brand	IPD
Series	Red Spot
Application	LV fuse fitting for utility and industrial installations
Rated Current	100 A
Rated Voltage	690 VAC
No. of Poles	1P
Cable Entry	95 sq-mm
Colour	White
Connection/Termination	2 stud rear connection
Fixing Centres	94 mm
Material	Flame-retardant non-hygroscopic material
Mounting	Screw
Depth	100 mm
Height	140 mm
Width	51 mm
IP Rating	IP20
Standards and Approvals	BS 88-2, AS 60269, IEC 269-2-1

IPD RS100PWH Fuse Fitting 100A 690VAC White (2) Stud IP20 For: RS100CLINK
