Specifications

Product Type	Fuse link
Brand	Mersen
Series	A4BQ
Application	Mains, feeders, large motors, lighting/heating loads, circuit breaker backup, UPS DC links and battery disconnects
Utilization Category	Class L
Breaking Capacity	200 kA AC / 100 kA DC
Rated Current	2000 A
Rated Frequency	50/60 Hz
Rated Voltage	600 V AC / 500 V DC
Speed Class	Time delay
Body Style	Cylindrical
Connection/Termination	Knife blade
Indicators	without indicator
Material	Fiberglass body, silver-plated copper blades
Mounting	Holder or bolted blade mounting
Length	273 mm
Weight	3.97 kg (Approx.)
Width	Ø 89 mm
Standards and Approvals	UL 248-10; CSA C22.2 No. 248.10

Mersen A4BQ2000 Time Delay Current-Limiting Fuse 2000A 600/500VAC/DC 89mmDia 97mm L Class L 200kA Bolt-In
