Specifications

Product Type	Time Delay Current-Limiting Fuse
Brand	MERSEN
Body Material	GMG
Body Size	5 in Dia x 10.75 in L
Body Style	Bolted Tag
Breaking Capacity	200 kA
Connection/Terminal Material	Silver Plated Copper
Diameter	127 mm
Fuse Class	Class L
Insulation Material	GMG
Length	97 mm
Mounting Type	Bolt-In
Rated Current	3000 A
Rated Frequency	50/60 Hz
Rated Voltage	600/500 VAC/VDC
Terminal Type	Blade
Weight	17.09 lb

Mersen A4BQ3000 Time Delay Current-Limiting Fuse 3000A 600/500VAC/DC 127mmDia 97mm L Class L 200kA Bolt-In
