Specifications

Product Type	Fuse link
Brand	Mersen
Series	A4BQ
Application	Mains, feeders, large motors, lighting/heating loads and circuit breaker backup
Utilization Category	Class L
Breaking Capacity	200 kA AC
Rated Current	3500 A
Rated Frequency	50/60 Hz
Rated Voltage	600 V AC
Speed Class	Time delay
Body Style	Cylindrical
Connection/Termination	Knife blade
Indicators	without indicator
Material	Fiberglass body, silver-plated copper blades
Mounting	Holder or bolted blade mounting
Length	273 mm
Weight	1.133 kg (Approx.)
Width	Ø 146 mm
Standards and Approvals	UL 248-10; CSA C22.2 No. 248.10

Mersen A4BQ3500 Time Delay Current-Limiting Fuse 3500A 600VAC 146mmDia 97mm L Class L 200kA Bolt-In
