Specifications

Product Type	Time Delay Current-Limiting Fuse
Brand	MERSEN
Body Material	GMG
Body Size	5.75 in Dia x 10.75 in L
Body Style	Bolted Tag
Breaking Capacity	200 kA
Connection/Terminal Material	Silver Plated Copper
Diameter	146 mm
Fuse Class	Class L
Insulation Material	GMG
Length	97 mm
Mounting Type	Bolt-In
Rated Current	4000 A
Rated Frequency	50/60 Hz
Rated Voltage	600 VAC
Terminal Type	Blade
Weight	2.5 lb

Mersen A4BQ4000 Time Delay Current-Limiting Fuse 4000A 600VAC 146mmDia 97mm L Class L 200kA Bolt-In
