Specifications

Product Type	Fuse Link
Brand	Mersen
Series	A4BQ
Application	Main/feeder circuits, motors, lighting, heating, general loads, breaker backup, and DC systems.
Utilization Category	Class L
Breaking Capacity	200 kA AC / 100 kA DC
Rated Current	700 A
Rated Frequency	50/60 Hz
Rated Voltage	600 V AC / 500 V DC
Speed Class	Time Delay
Body Style	Cylindrical
Connection/Termination	Bolted blade terminals
Indicators	No indicator
Material	Body: Fiberglass, Element: Pure silver
Mounting	Bolt-in
Size Code	Class L
Length	219 mm
Weight	1.71 kg (Approx.)
Width	Ø 63 mm
Standards and Approvals	UL Listed to UL 248-10; DC Listed to UL 248; CSA C22.2 No. 248.10

Mersen A4BQ700 Time Delay Current-Limiting Fuse 700A 600/500VAC/DC 63mmDia 97mm L Class L 200kA Bolt-In
