Specifications

Product Type	Midget fast-acting fuse
Brand	Mersen
Series	ATM
Application	Supplemental protection of circuits up to 600 V AC/DC, small motors, transformers and control circuits
Breaking Capacity	100 kA
Rated Current	3 A
Rated Frequency	50/60 Hz
Rated Voltage	600 V AC/DC
Speed Class	Fast acting
Body Style	Cylindrical / ferrule
Connection/Termination	Ferrule end caps
Indicators	without indicator
Material	Glass body; metal end caps
Mounting	Fuse holder / clips
Size Code	10 x 38
Length	38 mm
Weight	0.0064 kg
Width	Ø 10 mm
Standards and Approvals	UL 248-14; CSA C22.2 No. 248.14
