Specifications

Brand	Mersen
No. of Poles (Total)	1
Rated Current	310 A
Rated Voltage	600/1500 VAC/VDC
Wire Range	350 mcm, 2/0-14 AWG
Cable Type	Cu/Al
Cover Colour	Grey
Material	Nylon body; tin-plated aluminium connector
Mounting Type	DIN rail (35 mm)
No. of Holes	10
Sealable	No
Tightening Torque	Primary: 350–3/0 AWG 200 lb-in; 2/0–#1 AWG 100 lb-in; #2–#6 AWG 80 lb-in; #8–#14 AWG 35 lb-in; Secondary: #8–#14 AWG 35 lb-in
Depth	100.8 mm
Height	64.3 mm
Weight	0.3039 kg
Width	46.9 mm
IP Rating	IP20
Standards and Approvals	IEC 947-7-1; IEC 529; IEC 68-2-6; CE; RoHS
