MERSEN FUSE LINK 32A 690V 14*51MM FOR SEMICONDUCTOR PROTECTION + TRIP INDICATOR 14GR32 14F32 Q1017189

Product Code: Q1017189

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type High-speed fuse-link
Brand Mersen
Application Semiconductor protection for power electronic systems.
Suitable For 14x51 fuse holders
Utilization Category gR
Breaking Capacity 200 kA AC
Rated Current 32 A
Rated Voltage 690 V AC
Speed Class Ultra fast acting
Body Style Cylindrical
Connection/Termination Ferrule end caps
Indicators Trip indicator / striker
Material Ceramic body, silver-plated copper contacts
Mounting Ferrule
Size Code 14 x 51
Length 51 mm
Width Ø 14.3 mm
Standards and Approvals IEC 60269-4

Documents

IPD Product Catalogue V17
