Specifications

Product Type	Semiconductor fuse link
Brand	Mersen
Series	Protistor
Application	Semiconductor protection
Utilization Category	gR
Breaking Capacity	160 kA
Power Loss	7.5 W
Rated Current	40 A
Rated Voltage	690 V
Speed Class	gR
Body Style	Cylindrical
Connection/Termination	Ferrule end caps
Indicators	Trip indicator
Material	Body: Ceramic; Contact: Silver plated copper
Mounting	Fuse holder / clip
Size Code	14 x 51
Length	51 mm
Weight	0.020 kg (Approx.)
Width	Ø14.3 mm
Standards and Approvals	IEC 60269-1 & -4 UL, CCC, CE, UKCA

MERSEN FUSE LINK 40A 690V 14*51MM FOR SEMICONDUCTOR PROTECTION + TRIP INDICATOR 14GR40 14F40 S1017191
