Specifications

Product Type	Square body high-speed fuse-link
Brand	Mersen
Series	Protistor NH000 gS 690VAC
Application	Semiconductor protection for inverters, motor drives, UPS systems and similar equipment up to 700 V
Utilization Category	gS
Breaking Capacity	160 kA AC
Rated Current	40 A
Rated Voltage	690 V AC
Speed Class	High speed / fast acting
Body Style	NH blade / square body
Connection/Termination	Blade contacts
Fixing Centres	68 mm
Fuse Holder	NH modular fuse holders
Indicators	Double indicator
Material	Body:Ceramic, silver-plated contacts
Mounting	NH fuse base / fuse switch disconnector
Size Code	NH000
Height	52 mm
Length	78 mm
Weight	0.13 kg (Approx.)
Width	21 mm
Standards and Approvals	IEC 60269-4; DIN 43620/00; CCC GB 13539.4

MERSEN FUSE LINK 40A 690V gS 000 DIN FOR SEMICONDUCTOR PROTECTION USE NH FUSE BASES B322047
