Specifications

Product Type	High-speed fuse-link
Brand	Mersen
Application	Semiconductor protection for power electronic systems.
Utilization Category	aR
Breaking Capacity	200 kA AC
Rated Current	500 A
Rated Voltage	690 V AC
Speed Class	Ultra fast acting
Body Style	Square body
Connection/Termination	DIN 110 blades
Fixing Centres	110 mm
Indicators	Striker
Material	Ceramic body, silver-plated copper contacts, non-magnetic hardware, silica sand filler
Mounting	DIN 110 blades
Size Code	Size 31
Depth	56.5 mm
Length	134.6 mm
Weight	0.39 kg (Approx.)
Width	51 mm
Standards and Approvals	IEC 60269-4

MERSEN FUSE LINK 500A 110MM FIXING FOR SEMICONDUCTOR PROTECTION BODY SIZE 31, 660V N300024
