Specifications

Product Type	Fuse link
Brand	Mersen
Application	Small inverters, UPS systems and motor drives
Utilization Category	gR
Breaking Capacity	160 kA AC
Rated Current	50 A
Rated Voltage	690 V AC
Speed Class	High speed / fast acting
Body Style	Cylindrical
Connection/Termination	Ferrule end caps
Indicators	With striker
Material	Ceramic body, silver fuse elements, silver-plated copper end caps
Mounting	22x58 fuse holder
Size Code	22 x 58
Length	58 mm
Weight	0.06 kg (Approx.)
Width	Ø 22.2 mm
Standards and Approvals	IEC 60269-4; UL 248-13; CCC GB 13539.4

MERSEN FUSE LINK 50A 690V 22*58MM FR22GR69V50T WITH TRIP INDICATOR 22F50 22GR50 C1018626
