MERSEN FUSE LINK 550A 110MM FIXING FOR SEMICONDUCTOR PROTECTION BODY SIZE 31, 660V P300025

Product Code: P300025

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type High-speed semiconductor fuse
Brand Mersen
Application Protection of power semiconductors: diodes, thyristors, IGBT and MOSFET devices
Utilization Category aR
Breaking Capacity 200 kA
Rated Current 550 A
Rated Frequency 50/60 Hz
Rated Voltage 690 V AC
Speed Class Ultra-fast acting
Body Style Square body
Connection/Termination DIN 110 blades
Fixing Centres 110 mm
Indicators with striker
Material Silver-plated contacts; non-magnetic
Mounting Blade / bolted mounting
Size Code Body size 31
Weight 0.41 kg
Standards and Approvals IEC 60269-1; IEC 60269-4; UL recognized file E76491
