Specifications

Product Type	Fuse Link
Brand	Mersen
Application	Power semiconductor protection
Utilization Category	gR
Breaking Capacity	160 kA
Rated Current	80 A
Rated Voltage	690 V AC
Speed Class	gR
Body Style	Cylindrical
Connection/Termination	Ferrule end caps
Indicators	With striker / trip-indicator
Material	Body:Ceramic, Terminal: Silver plated copper
Mounting	Clip
Size Code	22 x 58
Length	58 mm
Weight	0.060 kg (Approx.)
Width	Ø 22.2 mm
Standards and Approvals	IEC 60269-1 & -4; UL 248-13; CCC GB 13539.4; RoHS

MERSEN FUSE LINK 80A 690V 22*58MM FR22GR69V80T WITH TRIP INDICATOR 22F80 22GR80 E1018628
