Specifications

Product Type	High-speed fuse-link
Brand	Mersen
Series	gR
Application	Semiconductor protection
Utilization Category	gR
Breaking Capacity	200 kA AC
Rated Current	80 A
Rated Frequency	50/60 Hz
Rated Voltage	690 V AC
Speed Class	gR
Body Style	Square body
Connection/Termination	DIN 80 blades
Indicators	Striker
Material	Body: Ceramic, Contact: Silver plated copper
Size Code	Size 000
Height	48 mm
Length	110 mm
Width	20 mm
Standards and Approvals	IEC 60269-4; DIN 43620

MERSEN FUSE LINK 80A GRB 80MM FIXING FOR SEMICONDUCTOR PROTECTION BODY SIZE 000, 660V Q330179
