Specifications

Product Type	Fuse Link
Brand	Mersen
Series	NH
Application	General purpose cable and line protection
Utilization Category	gG
Breaking Capacity	120 kA
Rated Current	500 A
Rated Voltage	500 V AC / 250 V DC
Body Style	Square body
Connection/Termination	Knife blade
Indicators	Double indicator
Material	Body:Ceramic, silver-plated copper contacts
Size Code	NH3
Length	150 mm (approx.)
Weight	0.65 kg (Approx.)
Width	70 mm (approx.)
Standards and Approvals	IEC 60269-1 and -2, VDE 0636 Part 201

Mersen NHG3-500 Time-Delay Midget Fuse 500A 500VAC
