Specifications

Product Type	Fast Acting Fuse
Brand	MERSEN
Body Material	Poly Tube
Body Size	1.56 in Dia x 7.13 in L
Body Style	Blade
Breaking Capacity	50 kA
Connection/Terminal Material	Tin Plated Copper
Fuse Class	Class K5
Insulation Material	PolyTube
Mounting Type	Clip
Rated Current	200 A
Rated Frequency	50/60 Hz
Rated Voltage	250 VAC/VDC
Terminal Type	Blade
Weight	0.733 lb

Mersen OT200 Fast-Acting General Purpose Fuse 200A 250VAC/DC Class K5 1.56 in Dia x 7.13 in L Blade Terminal
