Specifications

Product Type	Fuse Link
Brand	Mersen
Series	OT
Application	Feeders, Branch circuit, Residential and small commercial installations
Breaking Capacity	50 kA
Rated Current	225 A
Rated Voltage	250 V AC
Speed Class	Fast-acting
Body Style	Cylindrical
Connection/Termination	Blade
Material	Fiber body, metal caps
Length	219 mm
Width	Ø 53 mm
Standards and Approvals	UL 248-9,UL, CSA, RoHS

Mersen OT225 Fast-Acting General Purpose Fuse 225A 250VAC/DC Class K5 2.06 in Dia x 8.63 in L Blade Terminal
