Specifications

Product Type	Class K5 fast-acting fuse
Brand	Mersen
Series	OT
Application	General purpose branch-circuit and equipment protection
Utilization Category	Class K5
Breaking Capacity	50 kA
Rated Current	90 A
Rated Frequency	50/60 Hz
Rated Voltage	250 V AC/DC
Speed Class	Fast acting
Body Style	Blade type
Connection/Termination	Blade terminals
Indicators	without indicator
Mounting	Blade / bolted mounting
Size Code	Class K5 blade
Standards and Approvals	UL 248-9; CSA C22.2 No. 248.9

Mersen OT90 Fast-Acting General Purpose Fuse 90A 250VAC/DC Class K5 1.06 in Dia x 5.88 in L Blade Terminal
