Specifications

Product Type	Class K5 fast-acting fuse
Brand	Mersen
Series	OTS
Application	General purpose branch-circuit and equipment protection
Utilization Category	Class K5
Breaking Capacity	50 kA
Rated Current	60 A
Rated Frequency	50/60 Hz
Rated Voltage	600 V AC / 300 V DC
Speed Class	Fast acting
Body Style	Cylindrical / ferrule
Connection/Termination	Ferrule end caps
Indicators	without indicator
Mounting	Clip-in fuse holder
Size Code	27 x 139
Length	139 mm
Weight	0.0975 kg
Width	Ø 27 mm
Standards and Approvals	UL 248-9; CSA C22.2 No. 248.9

Mersen OTS60 Fast-Acting General Purpose Fuse 60A 600/300VAC/DC Class K5 1.06 in Dia x 5.5 in L Ferrule Terminal
