Specifications

Product Type	Fuse Link
Brand	Mersen
Series	SBS
Application	Control circuits, lighting ballasts, meter circuits, electronic circuits and general purpose protection
Breaking Capacity	100 kA
Rated Current	8 A
Rated Frequency	50/60 Hz
Rated Voltage	600 V AC
Speed Class	Fast-Acting
Body Style	Cylindrical
Connection/Termination	Ferrule end caps
Indicators	No indicator
Material	Body: Fiberglass
Mounting	Clip
Size Code	13/32 x 1 3/8
Length	34.93 mm
Weight	0.0073 kg (Approx.)
Width	Ø10.32 mm
Standards and Approvals	UL Listed to UL 248-14 (File E33925), CSA Certified to C22.2 No. 248.14
