Specifications

Product Type	Midget time-delay fuse
Brand	Mersen
Series	Tri-Onic TRM
Application	Small motors, small transformers, lighting circuits and control circuits
Breaking Capacity	10 kA
Rated Current	6 A
Rated Frequency	50/60 Hz
Rated Voltage	250 V AC
Speed Class	Time delay
Body Style	Ferrule / cylindrical
Connection/Termination	Ferrule end caps
Indicators	No
Size Code	38 x 10
Length	38 mm
Weight	0.0059 kg
Width	Ø 10 mm
Standards and Approvals	UL 248-14, CSA C22.2 No. 248.14
