Specifications

Product Type	Sensor
Brand	Panasonic
Series	FX - 100
Sensing Type	Fiber optic
Type of Switching Output	NPN-Output
Indication	Orange LED (Indicates when Output = ON)
Electrical Connection	Cable
Light Source	Red LED (Peak emission wavelength: 643 nm 0.025 mil)
Output Type	NPN
Rated Voltage	12-24VDC
Sensor Type	Digital Sensor
Timer Relay Type	ON-delay / OFF-delay (period range 1ms to 1000ms)
Display Lines	4 digits (green) + 4 digits (red)
Housing Material	Polycarbonate
Material	Enclosure: Polycarbonate Key switch: Polycarbonate Fiber lock lever: PBT
Weight	35 g
Relative Humidity (Without condensation)	35 to 85%
Humidity	35-85%
Operating Temperature	–10 to +55 ?
