Specifications

Product Type	DC/DC Converter
Brand	Puls
Series	CD
Diagnostics	DC-OK LED and relay contact
Input Voltage	DC 48 V (±25 %)
Output Current - Nominal	10 A
Output Current - Range	10 - 8.6 A
Output Power	240 W
Output Voltage - Nominal	24 V DC
Output Voltage - Range	24-28 V
Efficiency	0.94
Terminal Type	Screw terminals
Housing Material	Body: Aluminium alloy, Cover: Zinc-plated steel
Mounting Style	DIN Rail
Depth	117 mm
Height	124 mm
Weight	0.520 kg
Width	42 mm
Approvals / Conformity	CE, RoHS, REACH, EAC
Operating Temperature	-25 to 70°C
IP Rating	IP20

Puls CD10.242 DC/DC Converter 48VDC 8A 240 Watt
