Specifications

Product Type	Power Supply
Brand	PULS
Series	Q
Connection Type	Spring Clamp
Degree of Protection	IP20
Depth	127 mm
Derating Temperature	12 W/deg C
Efficiency	94.3%
Harmonic Correction	Active
Height	124 mm
Input Type	Wide-Range
Inrush Current	9 A, 7 A
Inrush Current Limitation	Active
Mounting Type	DIN Rail
Operational Temperature	-25 to 70 deg C
Phase	1
Power Loss	29 W
Power Reserve Type	50%
Range	DIMENSION
Rated Current	10 A
Rated Power	480 W
Rated Voltage	110-150 VDC, 48 VDC
Ripple and Noise Voltage	100 mVpp
Standards and Approvals	Class I Div. 2 Canada - CSA, Class I Div. 2 USA - CSA, EU Declaration of Conformity, IEC 60950 CB Scheme, Korea Certification, Marine ABS, Marine DNV, UL 508 Canada, UL 508 USA, UL 60950-1 Canada, UL 60950-1 USA, UK Declaration of Conformity
Weight	1200 g
Width	82 mm

Puls QS20.481 Power Supply 1PH 110-150VDC 48VDC 10A 480 Watt 29 Watt DIN Rail Mount Spring Clamp IP20
